Naval Armor Solutions
Macario Technologies Private Limited delivers a wide range of customized, lightweight protection systems for naval vessels. Developed using advanced materials such as Ultra-High Molecular Weight Polyethylene (UHMWPE) and Boron Carbide, our solutions are tested and certified by globally recognized laboratories and trusted by end users worldwide.
These protection systems are engineered to safeguard vulnerable sections of ships and boats against a broad spectrum of threats, including small arms fire, armor-piercing rounds, anti-ship missile fragments, explosive blasts, and other modern battlefield hazards.
Most Vulnerable Protection Areas:
- Missile launch silos
- Command & Information Centers (CIC) / Commander’s cabins
- Vessel bridges
- External weapon stations
- Helicopter hangars
Key Features:
- Large single-panel sizes available (up to 1.30 m × 2.50 m)
- Ready-to-mount modular panels with simple installation
- Designed to withstand harsh marine environments
- Resistant to seawater, sunlight, UV exposure, oils, and temperature variations
- Available in ready-to-paint aluminum casing or with specialized surface coatings
Protection Capabilities:
- Certified protection against AK-47 and rifle fire
- Multi-hit resistance compliant with international standards (NIJ IIIA / III / IV)
Add-On Weight vs. Protection Level
| Protection Level | Ammunition | Add-on Weight (Kg/m²) |
|---|---|---|
| NIJ Level IIIA (NIJ 0108.01) | .44 Magnum / 9 mm (small arms) | 4.8 – 9.4 |
| NIJ Level III | 7.62 × 51 mm NATO Ball | 14 – 20 |
| NIJ Level III+ | 7.62 mm MSC (AK-47) | 16 – 24 |
| NIJ Level III++ | 7.62 mm MSC (AK-47) / 5.56 mm SS109 | 22 – 32 |
| NIJ Level IV | 7.62 mm M2 AP | 32 – 44 |
With minimal additional weight on the vessel, our solutions deliver maximum protection without compromising payload capacity or speed. This makes Macario’s naval armor systems the preferred choice for safeguarding mission-critical areas at sea.
